Opis techniczny

• RAMA

  F-Podium 29 Stealth Air Full Carbon, XCO Optimized Zero Suspension System, 100mm, XC Forward Geometry, Carbon Monoblock upper link, BSA bottom bracket, tapered head tube, HHG internal cable routing, dedicated 1X drivetrain design, Boost 12x148mm rear axle, shock mudguard, postmount rear brake mount.
• Widelec

  Fox 34 Step Cast Float FIT4 EVOL Factory Kashima, 110mm, tapered steerer tube,15x110mm Boost axle, offset 44mm. Settings: remote 2pos Push-unlock, compression micro-adjustment at low-speed, rebound, air preload, remote Fox dual pull
• Skok przód

  110 mm
• Amortyzator tylny

  Fox Float DPS SV EVOL Factory Kashima, 185x47,5mm. Settings: 2 position remote compression (open/lock), low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings
• Skok tył

  100 mm
• Przerzutka (tył)

  Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
• Manetki

  Sram Trigger GX Eagle, 12s, X-Actuation 1:1
• Hamulec przód

  Sram Level TL, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
• Hamulec tył

  Sram Level TL, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
• Dźwignie hamulcowe

  Sram Level TL, Direct Link actuation, tooled reach adjust, lever pivot bushings
• Mechanizm korbowy

  Sram X1 Carbon Eagle, Boost, DUB axle, Direct mount chain ring, S size: 170mm, M/L/XL size: 175mm
• Osprzęt

  Sram DUB BSA, sealed bearings, 73mm
• Headset

  Acros AZX-239 R1 Block Lock, ZS44/28.6 top, ZS56/40 bottom
• Kaseta

  Sram XG-1275, 10-50T, 12s
• Łańcuch

  Sram GX Eagle, 12s, Powerlock
• Kierownica

  ONOFF Helium Carbon 0.2, rise: 4.8mm, width: 760mm, 9º backsweep, 0º upsweep, 31.8mm barbore
• Mostek kierownicy

  MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: sizes S/M: 50mm, size L: 60mm, size XL: 70mm
• Sztyca

  ONOFF Helium Carbon 0-R, diameter 31.6mm, length 400mm
• Siodełko

  Fizik Antares R7
• Chwyty kierownicy

  ONOFF Desert, 1lock-on, 135mm
• Piasta przód

  Mavic, Boost 15x110mm, IS 6 bolts
• Piasta tył

  Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts, XD freehub
• Obręcze

  Mavic Crossmax Carbon XL R 29, 30mm internal width, hookless, tubeless ready, 24 spokes - Mavic straight-pull double butted, contactless lacing
• Opony

  F: Maxxis Rekon Race 29x2.35, EXO protection, tubeless ready, 120TPI, folding bead, R: Maxxis Rekon Race 29x2.35, EXO protection, tubeless ready, 120TPI, folding bead
• Rozmiar kół

  29"
• WAGA

  11,2 kg

Inny

• Kod produktu

  N23000807
