Opis techniczny

• RAMA

  Foxy 29 Stealth Air full Carbon, Zero Suspension System, 150mm travel, Forward Geometry, Carbon Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors.
• Widelec

  Öhlins RXF 36 M.2 29, 170mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber. Fork settings: C20 R40
• Skok przód

  170 mm
• Amortyzator tylny

  Öhlins TTX Air 205x65mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 30x8mm bottom bushings, C10 compression, R35 rebound. Volume reducers 16.000 (2xF+1E)
• Skok tył

  150 mm
• Przerzutka (tył)

  Sram X01 Eagle AXS, roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
• Manetki

  Sram Eagle AXS Rocker paddle, 12s
• Hamulec przód

  Sram Code RSC, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
• Hamulec tył

  Sram Code RSC, oversized 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
• Dźwignie hamulcowe

  Sram Code RSC, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
• Mechanizm korbowy

  Sram X01 Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
• Osprzęt

  Sram DUB BSA, sealed bearings, 73mm
• Headset

  Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
• Kaseta

  Sram XG-1295, 10-52T, 12s
• Łańcuch

  Sram GX Eagle, 12s, Powerlock
• Kierownica

  ONOFF Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
• Mostek kierownicy

  ONOFF Krypton FG 30mm, CNC, 31.8mm barbore
• Sztyca

  ONOFF Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
• Siodełko

  SDG BEL-AIR 3.0, LPU foam, steel rails
• Chwyty kierownicy

  ONOFF Desert, 1lock-on, 135mm
• Piasta przód

  e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
• Piasta tył

  e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, XD freehub
• Obręcze

  e*thirteen Race Carbon Enduro IW30, Hookless carbon rim, 30mm internal width, tubeless ready, 28 spokes - e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers
• Opony

  F: Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead, R: Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
• Rozmiar kół

  29"
• WAGA

  13.9 kg

Inny

• Kod produktu

  N23000802
